- Westin Off-Road Series 11,000LBS Steel Cable Winch | 47-1411
)
Product Description
Westin Automotive Off-road Series Steel Cable 8500 LBS Winch Corded hand Control #47-1411
| Rope: | Galvanized Aircraft Cable w/Replaceable Clevis Hook |
| Length 94ft. (28m) of 5/16" (8.2mm) Diameter | |
| Fairlead: | 4-Way Roller Farilead (#47-3400) |
| Weight: | 95 lbs. |
| Rated Line Pull: | 11,000 lbs (4985 kgs) Single-Line |
| Motor: | 5.5HP/12V Series-Wound |
| Controler: | Corded Hand-held Control Included (12' lead / 3.7 m) |
| Solenoid Style: | Integrated Solenoid Module (ISM) |
| Gear Train: | 3 Stage Planetary |
| Gear Ratio: | 265:01:00 |
| Clutch: | Sliding Ring Gear |
| Brakes: | Automatic In-The Drum |
| Drum Size: | 2.52” Diameter x 8.82” Length (64 x 224 mm) |
| Recommended Battery: | 650CCA minimum for winching |
| Battery Leads: | 2 guage, 72” (1.83 m) |
| Finish: | Dark Gray |
| Overall Dimmensions: | (L x W x H) 21.3” x 6.3” x 8.6”, (541 x 160 x 218 mm) |
| Mounting Bolt Pattern: | 10.00” + 0.015” x 4.50” + 0.010”, (254 x 114.3 mm) |
Warranty Information
All warranties are offered by the manufacturer and not by Powerlabsdiesel.com.
Three Year Limited Warranty
Westin Automotive Products, Inc. guarantees the original purchaser of Westin products a three year warranty from the date of original purchase against manufacturer defects in materials, workmanship and finish under normal use excluding damage resulting from road hazards such as gravel or other debris, product misuse, improper installation, impairments from accidents, product modifications or product neglect. This three year warranty applies only to new products and is limited to the repair or replacement of Westin products. Warranty does not include electrical components or light bulb replacement, costs of removal, installation, labor, freight, inconvenience or consequential damages. Original purchaser must return defective merchandise, along with the purchase receipt, to the original place of purchase. This warranty does not cover damage resulting from accident, misuse, neglect, improper installation, fire, vandalism or any form of abuse.
